Additional information
| Model | SIVACON S4 |
|---|---|
| Rated current main busbar In | 630 A – 4.000 A |
| Rated short-time withstand current lcw | 100 kA, 1s |
| Rated peak withstand current lpk | 220 KA |
| ACB main busbar coupling IN | Up to 3.200 A |
| Form of internal separation | Form 4b |
| Installation | Single-fronted |
| Panel depth mm | 400, 600, 800 |
| Panel height mm | 2.000 |
| Business model | Part business via Industry Mall |
| Technical support | Siemens hotline/SIOS |
