ELITECH Temperature Controller Thermostat Remote Monitoring Greenhouse 1100W 110V 10A STC-1000WiFi

banner

ELITECH Temperature Controller Thermostat Remote Monitoring Greenhouse 1100W 110V 10A STC-1000WiFi

Brand

Elitech

รุ่น

STC-1000WiFi

Download Documents

Additional information

Model

STC-1000WiFi

Power supply

110-240VAC, 50/60HZ

Total power consumption

5W

Temperature measuring range

-45°C ~ 115°C/-49 ~ 239°F

Temperature control range

-40°C ~ 110°C/-40 ~ 230°F

Temperature resolution

0.1C/0.1°F

Temperature accuracy

±1°C/±2°F

Operating ambient temperature

-10°C~ˇ65°C / 14°F ~ 149°F

Storage temperature

-20°C~75°C / -4°F ~ 167°F

Relay contact capacity

10A /110~240VAC

Sensor type

NTC Temperature Sensor(10KQ/ 25C, B value=3435K

Working mode

Heating or Cooling

Cable length(Sensor)

2m

Cable length(Power plug)

1.5m

Cable length(Heating/Cooling Outlet)

0.3m

Dimensions

265mm x 1675mm

Best LCD screen viewpoint

6 o'clock position

WiFi type

2.4GHz WiFi

Feature

  • [Remote Monitoring via WiFi] Set the parameter and view data, graph, alarm history through our Elitech iCold platform or free APP.
  • [Dual Relay Output] Be able to connect with cooling and heating device at the same time.
  • [Wide Temperature Range] It measures from -49℉~239℉ and starts cooling or heating according to set parameters, which helps to keep the desired temperature all the time.
  • [Multi-functional Setting] Its functions include setting high or low alarms, start delay, temperature calibration, ℃/℉ and etc.
  • [Safe & Reliable]Comply with CE, FCC standards and adopt fireproof ABS case, UL94 V-0 for safety.

Package Included

  • 1 x STC-1000WiFi Thermostat
  • 1 x Heating Outlet(11.8 in./0.3m)
  • 1 x Cooling Outlet(11.8 in./0.3m)
  • 1 x US Power Plug(59 in./1.5m)
  • 1 x Temperature Sensor(78.7 in./2m)
  • 1 X User Manual
